surge protector

Surge protection circuit is a device that will provide surge suppression so that sensitive device will not damage.

Surge protection can handle voltage Spike as high as some kilovolt range Depending On The type of surge protection device.

Design to withstand high voltage spike in a short period of time, it is not rated to handle high voltage in longer duration.

Surge is voltage transient, voltage surge or voltage spike.

Is not a permanent event it is occurring within a short period of time but more than enough to destroy devices if there is no counter measure.

       •UNIVERSAL SURGE PROTECTION•

  Two Major Types Of Surge>>>>

1• Primary surge protection device :is installed in the entry point of the house, it is very powerful; however it is huge and bulky as well as expensive.

2• Uninterruptible power supply(UPS]•>>>inbuilt surge system.

       •SURGE SYSTEM•

A• There is a kind of surge protection device that can shutdown once there is a voltage surge. This type of surge protector is sophisticated, more complex and more expensive. The basic components of this type are voltage sensor, controller and latch/unlatch circuit voltage sensor will monitor the line voltage, the controller will read the sense voltage and decide when to send signal voltage termination to the latch/unlatch circuit. The latch/unlatch circuit is a controllable power contactor or power switch that can be able to connect or disconnect the line voltage⚡•

B• There is a kind o
